Does material choice affect crack resistance?

Yes, it does. High-quality refractories with fewer pores resist cracks more. Plants using denser materials have up to 30% fewer failures. Picking the right material makes parts stronger and helps them handle thermal shock.

Why does nozzle clogging increase cracking risk?

Clogged nozzles cause uneven pressure and stress. This stress can make cracks or leaks. More cracks show up when inclusions block the nozzle, especially when steel flows fast.

What maintenance steps help prevent cracking?

Teams should check parts often and line up shrouds carefully. They need to control heating rates. Using logs and photos helps track wear. Plants with strict maintenance plans have longer part life and fewer leaks.

Ladle Shroud Gasket – Material, Function, Shape & Installation Guide

How to Use the Ladle Shroud Manipulator in Continuous Casting Operations

Refractory shapes and sizes



Operation procedure of dry material for induction furnace

Drawing design method and skill of ladle slide gate plate
slide gate plate test report In AK Middletown 225-ton ladle
Recycling slide gate plates to save costs and reduce waste
The top 5 ladle shroud manufacturers in China
The Role of Slide Gate Plates in Steel Industry Efficiency: Exploring the Mechanisms of LS, CS, and LG Series for Optimal Performance

The difference between magnesia carbon brick and aluminum magnesia carbon brick

Production and application of isostatically pressed refractory materials
New generation ladle slide gate system for performance improvement
Thermal Stress Cracking Of Ladle Slide Gate Plate
The-damage-reasons-to-ladle-sliding-plates-and-the-advantages-and-disadvantages-of-some-slide-gate-plates
The Unseen Champion Of Continuous Steel Casting-Slide Gate
5 Key Factors Behind Ladle Shroud Cracking
How To Extend The Service Life Of Slide Gate Plates In Steel Casting - Henan Yangyu Refractories Co.,Ltd
How To Choose Ladle Shroud From A China Factory
A Few Things You Should Know About The Ladle Nozzle
Wear Reason About The Slide Gate Plate
Before Enquiry Some Questions You Should Know About Ladle Shroud - Henan Yangyu Refractories Co.,Ltd
The Iso Refractory Trial Report Compared With Vesuvius
The drawing regarding kinds of slide gate plate
Slide Gate Plate Price Guide 2025: Complete Pricing Analysis and Buying Tips
Complete Guide to Submerged Entry Nozzle (SEN) in Steel Making
The ladle shroud nozzle for continuous casting is also called the protective sleeve. It is an important component connecting the ladle and the tundish. It is connected to the lower shroud of the sliding shroud device at the bottom of the ladle, and the lower end extends into the tundish.
The shroud is an important functional refractory material for maintaining casting and improving steel quality. The length of the shroud is generally 600-1800mm, the pipe diameter is 90-150 mm, and the structure of the ladle shroud nozzle is shown in Figure 2. Its use conditions are harsh and must have the following functions: excellent thermal shock resistance; good mechanical strength; excellent resistance to alternating corrosion of molten steel and slag, high oxidation resistance, and in addition, other suitable properties are required for some special steel grades.more information,please check here

Tundish nozzle
Slide Gate Plate is a critical component in the continuous casting process, used to control the flow of molten steel from the ladle or tundish to the crystallizer. The following is a detailed description:

Role and Function

• Flow Control: The sliding gate plate adjusts the opening size of the nozzle through the sliding mechanism, thereby controlling the flow of molten steel. This is very important for maintaining a constant and controllable casting process.
• Operational Flexibility: The sliding gate plate allows operators to adjust the molten steel flow rate as needed during the casting process to adapt to different production requirements and conditions.
• Emergency Stop: In an emergency, the sliding gate plate can completely close the flow channel and stop the flow of molten steel, thereby preventing accidents and losses.


Slide gate plate for Converter
The slide gate plate is made of sintered corundum, fused corundum, fused zirconium corundum, zirconium mullite and other main raw materials. It is combined with new resin, formed by high pressure and fired at high temperature. It has the advantages of high strength, super hard, high temperature resistance and corrosion resistance, and strong thermal stability.
Stopper

Monoblock Stopper is used mainly for flow control on Molten Steel poured from tundish to mould. Monolithic Stopper is installed in the Tundish above the Sub Entry Nozzle and the gap between stopper head and Nozzle decide the throughput requirement of Molten Steel inside the Mould.
Argon can be blown into the tundish through argon inlet to prevent nozzle from Clogging ( specially designed feature wherever it is required we design and customise accordingly)
SPECIAL FEATURES:
o Facility for gas purging
o Anti oxidant properties
o Design and size as per customer’s requirement
o Clogging free casting for long sequence of casting
o Gas purging facilities to prevent alumina clogging (optional)
o Slag zone immersed part re-inforcement with special material for long life
o Argon sealing purging arrangement can be provided on customer’s request
o Wide range of formulation for withstanding oxidation and long sequence casting
o Different assembly methods for assured security even in long sequence casting
o We manufacture Silica free Oxy-bore ladle shroud for less corrosion and long sequence casting
